1. SEATING CAPACITY : 533 SEATS
2. NUMBER OF ROW : 12 ROW
3. WIDTH SYSTEM : 23,824 mm
4. EXTENDED DEPTH OF SYSTEM (INCLUDE FRONT STEP) : 10,600 mm
5. RETRACTED DEPTH OF SYSTEM : 1,600 mm
6. OVERALL HEIGHT OF SYSTEM : 3,810 mm
7. DEPTH OF PLATFORM : 900 mm
8. HEIGHT OF PLATFORM : 300 mm
9. SIZE OF AISLE : 1.100 mm
10. CENTRE TO CENTRE PER SEAT : 460 mm
11. SEAT CENTRE : 460 mm
12. HEIGHT OF SEAT SHELL / BACKREST SHELL : 430 mm / 585 mm
13. CLOSE DEPTH : 200 mm
14. SEAT AND BACKREST SHELL : HDPE BLOW MOLDED SHELL
15. SEAT & BACKREST BRACKET : 3 mm T FOLDED STEEL PLATE
16. FIRE RETARDANT REGULATION : BS5852:2006, source 1
